SILICON NITRIDE

时间:2017-10-11 14:45    点击量:

Basic Property:
Pure silicon nitride is non-acidification ceramic, which has excellent performance in high-heat machinery. It has excellent heat-resistance and wearable capability. There are two types: alpha and beta types. The alpha type is mainly used as powder material for moldings and the beta type is used as fillers to improve wearable resistance/thermal conductivity of resins, etc. The structure of silicon nitride is similar to diamond, and it can be heated to 1450-1550 in the air and 1750 in inert gases or the environment of deoxidization. If the temperature is higher, the decomposition is more severe. We can supply ultra fine powder whose average particle size ranges from sub-micron to coarse grain powder.
Feature:
Moldings using silicon nitride powder are light, having excellent strength at high temperature, toughness against breakage, and quite sensational characteristics such as wearability, resistance to corrosion and oxidation and thermal shock, etc. This is a material applied in components for automotive engines, electronics and industrial machinery, as well as in various types of composite materials, etc. It can be synthesized from the silicon powder heated to 1200-1450 in the atmosphere of ammonia, nitrogen and nitrogen-hydrogen or from the mixture of silicon dioxide and excessive carbon powder in the atmosphere of nitrogen at 1400.
Chemical composition:

Kinds of commodity Silicon nitride
α-Si3N4
Silicon nitride
β-Si3N4
α, β content α>92% β>95%
Chemical composition
(Wt.%)
N >37.0 >37.0
O <1.5 <1.5
C <0.1 <0.1
Fe <0.2 <0.3
Physical property Granularity (D50) <1um <5-10um, 200 mesh
Specific surface area (SSA) >10m2/g >3-5 m2/g
Molecular weight 140.5 140.3
Density (g/cm3) 3.2 3.14
Expansion coefficient
×10-6K-1
2.8 2.8
Resistance coefficient (Ω.cm) 1013 1013
Micro hardness kg/mm2 3500 2800
Grain size It can be supplied and produced according to buyers’ requirements.
Use:
(1) Thermal engine components: Automotive engine components, gas turbine components, etc.
(2) Mechanical components: Cutting tools, bearings, etc.
(3) Corrosion resistance components: melted aluminum-related components, etc.
(4) General industrial components: wearable components, high temperature insulation components, heat resistant containers and tools, etc.
(5) Material for resin filling: wearable, thermal conductive filler, etc.
(6) Silicon nitride ceramic has been one of important materials for metal cutting tools, and it is being developed to apply to gas engine.
(7) The sintering silicon nitride can be made into pipe, crucible and nozzle, etc so that it can satisfy various special requirements.
The XRD patterns of the SHS-synthesized Si3N4 powders:
u       α1=72.3%(Fig. 8) u       α2=73.7%(Fig.9)
